Exploring Relationships Among CIA Factbook Variables

This figure shows correlations between various CIA Factbook variables. Large circles indicate strong correlations, with positive values in teal and negative values in orange.

Figure 1: Correlation heatmap of CIA Factbook variables. It shows correlations between birth rate, death rate, and life expectancy. Larger circles indicate stronger correlations, with positive correlations in teal and negative correlations in orange.

Steps to Create this Graphic

1. Load Packages & Setup

```{r}
#| label: load
#| warning: false

## 1. LOAD PACKAGES & SETUP ----
if (!require("pacman")) install.packages("pacman")
pacman::p_load(
    tidyverse,         # Easily Install and Load the 'Tidyverse'
    ggtext,            # Improved Text Rendering Support for 'ggplot2'
    showtext,          # Using Fonts More Easily in R Graphs
    janitor,           # Simple Tools for Examining and Cleaning Dirty Data
    skimr,             # Compact and Flexible Summaries of Data
    scales,            # Scale Functions for Visualization
    lubridate,         # Make Dealing with Dates a Little Easier
    glue,              # Interpreted String Literals
    patchwork,         # The Composer of Plots
    here,              # A Simpler Way to Find Your Files
    ggcorrplot,        # Correlogram
    camcorder          # Record plots
)

### |- figure size ----
camcorder::gg_record(
    dir    = here::here("temp_plots"),
    device = "png",
    width  =  10,
    height =  10,
    units  = "in",
    dpi    = 320
)

### |- resolution ----
showtext_opts(dpi = 320, regular.wt = 300, bold.wt = 800)
```

2. Read in the Data

```{r}
#| label: read
#| include: true
#| eval: true
#| warning: false

tt <-tidytuesdayR::tt_load(2024, week = 06)
tt <-tidytuesdayR::tt_load(2024, week = 43)

cia_factbook <- tt$cia_factbook |> clean_names()

tidytuesdayR::readme(tt)
rm(tt)
```

3. Examine the Data

```{r}
#| label: examine
#| include: true
#| eval: true
#| results: 'hide'
#| warning: false

glimpse(cia_factbook)
skim(cia_factbook)
```

4. Tidy Data

```{r}
#| label: tidy
#| warning: false

### |- tidy data ----
# Select numeric variables and compute correlation matrix
cor_matrix <- cia_factbook |>
    select(where(is.numeric)) |>
    cor(use = "complete.obs")

# Clean column names for better readability in plots
colnames(cor_matrix) <- gsub("_", " ", colnames(cor_matrix)) |> str_to_title()
rownames(cor_matrix) <- gsub("_", " ", rownames(cor_matrix)) |> str_to_title()

# Convert correlation matrix to a long format for plotting labels
cor_df <- as.data.frame(as.table(cor_matrix)) |>
    rename(Var1 = Var1, Var2 = Var2, Correlation = Freq) |>
    filter(!is.na(Correlation))
```

5. Visualization Parameters

```{r}
#| label: params
#| include: true
#| warning: false

### |- plot aesthetics ----
bkg_col      <- colorspace::lighten('#f7f5e9', 0.05)
title_col    <- "gray20"
subtitle_col <- "gray20"
caption_col  <- "gray30"
text_col     <- "gray20"
col_palette  <- paletteer::paletteer_d("NineteenEightyR::miami1")[c(1,3,5)]
# show_col(col_palette)

### |-  titles and caption ----
# icons
tt <- str_glue("#TidyTuesday: { 2024 } Week { 43 } &bull; Source: usdatasets R package<br>")
li <- str_glue("<span style='font-family:fa6-brands'>&#xf08c;</span>")
gh <- str_glue("<span style='font-family:fa6-brands'>&#xf09b;</span>")
mn <- str_glue("<span style='font-family:fa6-brands'>&#xf4f6;</span>")

# text
title_text    <- str_glue("Exploring Relationships Among CIA Factbook Variables")
subtitle_text <- str_glue("This figure shows correlations between various CIA Factbook variables.\nLarge circles indicate strong correlations, with positive values in teal and negative values in orange.")
caption_text  <- str_glue("{tt} {li} stevenponce &bull; {mn} @sponce1(graphic.social) {gh} poncest &bull; #rstats #ggplot2")

### |-  fonts ----
font_add("fa6-brands", here::here("fonts/6.4.2/Font Awesome 6 Brands-Regular-400.otf"))
font_add_google("Oswald", regular.wt = 400, family = "title")
font_add_google("Merriweather Sans", regular.wt = 400, family = "subtitle")
font_add_google("Merriweather Sans", regular.wt = 400, family = "text")
font_add_google("Noto Sans", regular.wt = 400, family = "caption")
font_add_google("Shadows Into Light", regular.wt = 400, family = "anotation")
showtext_auto(enable = TRUE)

### |-  plot theme ----
theme_set(theme_minimal(base_size = 14, base_family = "text"))

cor_theme <- function() {
    theme(
        plot.title.position   = "plot",
        plot.caption.position = "plot",
        plot.background       = element_rect(fill = bkg_col, color = bkg_col),
        panel.background      = element_rect(fill = bkg_col, color = bkg_col),
        plot.margin           = margin(t = 20, r = 20, b = 20, l = 20),
        panel.grid.minor      = element_blank(),
        panel.grid.major      = element_line(color = "gray80", size = 0.4, linetype = 'dotted'),
        axis.title            = element_blank(),
        axis.text.y           = element_text(color = text_col, family = "text", size = rel(1)),
        axis.text.x           = element_text(color = text_col, family = "text", size = rel(1), angle = 30, hjust = 1),
        axis.ticks.x          = element_line(color = text_col),
        axis.line.x           = element_line(color = "#252525", linewidth = .2)
    )
}
```

6. Plot

```{r}
#| label: plot
#| warning: false

### |- initial plot ----

# Create correlation heatmap with annotations
p <- cor_matrix |>

    # Geoms
    ggcorrplot(
        method = "circle", type = "lower",
        hc.order = TRUE, lab = FALSE, show.legend = TRUE,
        colors = col_palette, outline.color = "black",
        ggtheme = cor_theme()
    ) +

    # Scales
    scale_x_discrete() +
    scale_y_discrete() +
    scale_fill_stepsn(
        colors = col_palette,
        transform = "identity",
        guide = guide_colorsteps(
            barheight = unit(16, "lines"),
            barwidth = unit(.5, "lines")
        )
    ) +

    # Labs
    labs(
        x = NULL,
        y = NULL,
        title = title_text,
        subtitle = subtitle_text,
        caption = caption_text
    ) +

    # Theme
    theme(
        plot.title = element_text(
            size = rel(2),
            family = "title",
            face = "bold",
            color = title_col,
            lineheight = 1.1,
            margin = margin(t = 5, b = 5)
        ),
        plot.subtitle = element_text(
            size = rel(1),
            family = "subtitle",
            color = subtitle_col,
            lineheight = 1.1,
            margin = margin(t = 5, b = 5)
        ),
        plot.caption = element_markdown(
            size = rel(0.75),
            family = "caption",
            color = caption_col,
            lineheight = 1.1,
            hjust = 0.5,
            halign = 1,
            margin = margin(t = 15, b = 5)
        )
    )

### |- Annotated plot ----

# Add annotation text
annotation_text <- str_glue(
    "Variables like birth rate and infant mortality rate
    show a strong positive correlation, whereas others,
    such as life expectancy at birth and infant mortality rate,
    exhibit a strong negative correlation.

    These relationships suggest that countries
    with higher birth rates also tend to have
    higher infant mortality, indicating possible
    healthcare challenges."
)

p <- p +
    # text
    annotate(
        "text",
        x = 1, y = 7.3, label = annotation_text,
        family = "anotation",
        colour = text_col,
        size = 5,
        lineheight = 1.2,
        hjust = 0
    )
```

7. Save

```{r}
#| label: save
#| warning: false

### |-  plot image ----

# Save the plot as PNG
ggsave(
  filename = here::here("data_visualizations/TidyTuesday/2024/tt_2024_43.png"),
  plot = p,
  width = 10, height = 10, units = "in", dpi = 320
)

### |-  plot thumbnail----
magick::image_read(here::here("data_visualizations/TidyTuesday/2024/tt_2024_43.png")) |>
  magick::image_resize(geometry = "400") |>
  magick::image_write(here::here("data_visualizations/TidyTuesday/2024/thumbnails/tt_2024_43.png"))
```

8. Session Info

TipExpand for Session Info

R version 4.4.1 (2024-06-14 ucrt)
Platform: x86_64-w64-mingw32/x64
Running under: Windows 11 x64 (build 22631)

Matrix products: default


locale:
[1] LC_COLLATE=English_United States.utf8
[2] LC_CTYPE=English_United States.utf8
[3] LC_MONETARY=English_United States.utf8
[4] LC_NUMERIC=C
[5] LC_TIME=English_United States.utf8

time zone: America/New_York
tzcode source: internal

attached base packages:
[1] stats     graphics  grDevices datasets  utils     methods   base

other attached packages:
 [1] camcorder_0.1.0    ggcorrplot_0.1.4.1 here_1.0.1         patchwork_1.3.0
 [5] glue_1.8.0         scales_1.3.0       skimr_2.1.5        janitor_2.2.0
 [9] showtext_0.9-7     showtextdb_3.0     sysfonts_0.8.9     ggtext_0.1.2
[13] lubridate_1.9.3    forcats_1.0.0      stringr_1.5.1      dplyr_1.1.4
[17] purrr_1.0.2        readr_2.1.5        tidyr_1.3.1        tibble_3.2.1
[21] ggplot2_3.5.1      tidyverse_2.0.0    pacman_0.5.1

loaded via a namespace (and not attached):
 [1] tidyselect_1.2.1   farver_2.1.2       fastmap_1.2.0      gh_1.4.1
 [5] digest_0.6.37      timechange_0.3.0   lifecycle_1.0.4    rsvg_2.6.1
 [9] magrittr_2.0.3     compiler_4.4.0     rlang_1.1.6        tools_4.4.0
[13] utf8_1.2.4         yaml_2.3.10        knitr_1.49         labeling_0.4.3
[17] htmlwidgets_1.6.4  bit_4.5.0          curl_6.0.0         plyr_1.8.9
[21] xml2_1.3.6         repr_1.1.7         tidytuesdayR_1.1.2 withr_3.0.2
[25] grid_4.4.0         fansi_1.0.6        colorspace_2.1-1   paletteer_1.6.0
[29] gitcreds_0.1.2     cli_3.6.4          rmarkdown_2.29     crayon_1.5.3
[33] ragg_1.3.3         generics_0.1.3     rstudioapi_0.17.1  reshape2_1.4.4
[37] tzdb_0.5.0         commonmark_1.9.2   parallel_4.4.0     base64enc_0.1-3
[41] vctrs_0.6.5        jsonlite_1.8.9     hms_1.1.3          bit64_4.5.2
[45] systemfonts_1.1.0  magick_2.8.5       gifski_1.32.0-1    rematch2_2.1.2
[49] codetools_0.2-20   stringi_1.8.4      gtable_0.3.6       prismatic_1.1.2
[53] munsell_0.5.1      pillar_1.9.0       rappdirs_0.3.3     htmltools_0.5.8.1
[57] R6_2.5.1           httr2_1.0.6        textshaping_0.4.0  rprojroot_2.0.4
[61] vroom_1.6.5        evaluate_1.0.1     markdown_1.13      gridtext_0.1.5
[65] snakecase_0.11.1   renv_1.0.3         Rcpp_1.0.13-1      svglite_2.1.3
[69] xfun_0.49          pkgconfig_2.0.3

9. GitHub Repository

TipExpand for GitHub Repo

Access the GitHub repository here
